Features

1. Enamel Electrodes:
• Use enamel coating as internal electrode, stainless steel as external electrode,
capacity of corona resistance and machinery anti-force capacity are stronger than glass,
ceramic material.
• Uniformity air gap between enamel coating internal electrode and stainless
steel external electrode.
• it produces high concentration ozone output.
• It uses insulation materials for connections to prevent creepage.

2. Cooling way:
Water cooled for internal & external electrodes, effective prevent high temperature
rising when the tube is discharging, to ensure highconcentration of the ozone output.

3. Adjustable ozone output range: 20-100%.
Use high-frequency & Intelligent power supply inverse system, ozone output can be
changed on demand to achieve accuracy control.
